Shibaura Industrial Engine EGR & DPF Tune
Shibaura diesels power a long list of compact tractors, skid steers and loaders sold under the Case, New Holland, Massey Ferguson, LS and Perkins names. We turn off the EGR and DPF on the 1.5L, 1.9L and 2.2L engines, either remotely through Perkins EST with a CAT Comm adapter or by bench flashing the ECM in our shop. We ship all across the US and Canada.
FitsShibaura 1.5L, 1.9L & 2.2L
SystemsEGR · DPF
Found inCase · New Holland · MF · LS · Perkins
MethodRemote or bench flash
AdapterCAT Comm (remote)
Warranty1 year software
Which method fits your engine
Remote tunePerkins ESTCAT Comm adapter · Windows laptopYou plug a CAT Comm adapter into the diagnostic port and we take over your laptop with TeamViewer. Perkins EST writes the new file while the ECM stays bolted in place.
Bench flashSend the ECMNext business day turnaroundNo laptop or adapter on hand? Remove the engine control module and mail it to our shop. We program it on the bench and have it back in the mail the following business day.
FIRST, FOR EVERY SHIBAURA ENGINESend us a photo of the engine data plateShibaura plates are normally riveted to the valve cover or the side of the block. Along with the machine make and model, it tells us your displacement and which ECM we are working with.
Email data plate photo
Remote tune
Perkins EST · CAT Comm adapter
STEP 01OrderPick 1.5L, 1.9L or 2.2L, your machine brand, and add a CAT Comm adapter if you do not own one.
STEP 02ConnectHook the adapter up to the diagnostic plug and open a TeamViewer session.
STEP 03FlashOur tech reads the ECM in Perkins EST and writes the EGR and DPF delete file.
You’ll need
BEFORE STEP 02Download TeamViewer for WindowsDownload →
✓Windows laptop
✓TeamViewer installed
✓Strong internet connection
✓CAT Comm adapter
✓Battery charger
✓Key on, engine off
Prefer to mail it in? Bench flash
Select Bench Flashing at checkout and we email the steps for pulling, packing and shipping the ECM. It is programmed the day it lands and goes back out the next business day, ready to plug in.
After the tune
EXHAUSTHollow out or straight pipe the DPFWith the filter turned off in the file, empty out the DPF canister or swap it for a straight pipe.
EGRBlock-off plate recommendedThe file keeps the EGR valve closed. Sealing the passage with a block-off plate as well is cheap insurance against a valve that sticks open later.
Machines with Shibaura engines
Our most common Shibaura tunes, grouped by brand.
Massey FergusonCompact tractors
1726E1734E1739E
Case IHFarmall compact tractors
Farmall 35Farmall 40Farmall 45Farmall 50
New HollandWorkmaster tractors
Workmaster 33Workmaster 35Workmaster 40Workmaster 45Workmaster 50Workmaster 55
New HollandBoomer tractors
Boomer 33Boomer 41Boomer 47
LSXR series tractors
XR3032XR3037XR4040XR4046
Case CESkid steers
SR160SR175SV185
New HollandSkid steers
L213L215L218L220
NEW HOLLANDBoomer seriesEvery New Holland Boomer compact tractor runs a Shibaura engine.
CASE IHCompact Farmall tractorsThe small-displacement Farmall models are Shibaura powered.
CASE CE · NEW HOLLANDSmall-frame skid steersSmaller Case and New Holland skid steers use Shibaura diesels.
PERKINSC2.2 enginesThe Perkins C2.2 is a rebranded Shibaura engine, so it is covered by this tune.
Shibaura engines show up in many other machines too. If yours is not listed, email us the engine data plate and we will confirm.
Why delete the EGR and DPF on a Shibaura engine?
EGR
Exhaust gas recirculation
Compact tractors and skid steers spend hours at part throttle, and the EGR keeps pushing sooty exhaust back into a small intake the whole time. On a small Shibaura that carbon builds up fast, sticking the valve and clogging the cooler until the machine sets a code and loses power. With the EGR shut off, the engine breathes clean air again.
DPF
Diesel particulate filter
Mowing, loader work and chores around the yard rarely get a small diesel hot enough to clean its own filter. The machine ends up asking for parked regens, burning extra fuel and eventually needing the filter cleaned or replaced. Turning the DPF off and emptying the canister puts an end to that cycle.
Frequently asked questions
Q1How do I know if my machine has a Shibaura engine?+
Check the data plate on the valve cover or engine block. Every New Holland Boomer, the compact Farmall tractors and the smaller Case and New Holland skid steers use one, along with machines like the Massey Ferguson 1739E and LS XR4040.
Q2Should I choose remote tuning or bench flashing?+
Remote tuning is quickest if you have a Windows laptop and a CAT Comm adapter, since the ECM stays in the machine. Bench flashing suits anyone without the tools: you mail the ECM and we send it back the next business day.
Q3I already own a CAT Comm adapter. Can I use it?+
Yes. Let us know at checkout and we will use your adapter during the Perkins EST session. If you do not have one, add it to your order.
Q4Which displacement do I pick, 1.5L, 1.9L or 2.2L?+
The engine data plate lists the displacement. Send us a photo if you are unsure and we will confirm before you order.
Q5What do I do with the DPF afterwards?+
Once the file is installed, hollow out the DPF canister or replace it with a straight pipe. We also recommend an EGR block-off plate as a backup.
Q6Is there a warranty?+
Every Shibaura file carries a 1 year software warranty, whether it is flashed remotely or on our bench.
Q7Disclaimer+
For off-road use only and never on equipment registered for the highway. Check your state or provincial rules before you buy.
Why Reimer Tuning
Shibaura engines end up in machines from half a dozen brands, and we tune them all from the same in-house files. Remote or on the bench, the work is done by our own Canadian team, tuning diesel equipment since 2014, and each file is backed by a 1 year software warranty.
Emailing us? Attach a photo of your engine data plate.
Off-road use only. Not for machines registered for highway use. Buyers are responsible for knowing their provincial or state legislation. All sales final.
