2011-2016 Kubota SVL 90/90-2 Reflash

From $2,495.00

  • Reimer Tuning Reflash Master handheld device
Reflash Options
Horsepower Tunes
Exhaust Piping
$2,495.00
$2,495.00
Shipping calculated at checkout.

Want next day delivery? Be quick!

I18n Error: Missing interpolation value "end_date" for "Ends on {{ end_date }}"


Kubota SVL90 / SVL90-2 DPF & EGR Delete Tune

Get your SVL90 off the regen schedule and back on the job. Our Reflash Master handheld lets you tune the ECM at the machine and shut off the EGR and DPF systems for good, with no modules to pull or mail in. Add up to 20% more power with our Stage 1 and Stage 2 tunes. We ship all across the US and Canada.

FitsKubota SVL90 / SVL90-2, 2011–2016
SystemsEGR and DPF
TierTier 4 Interim
MethodReflash Master handheld
TurnaroundTuned file in 2 hours
PowerUp to 108 hp

Horsepower tunes · Kubota SVL90

KUBOTA SVL90 / SVL90-2
Stock90HP

Factory baseline
Stage 199HP

+9 hp · +10%
Stage 2108HP

+18 hp · +20%


Kit includes

01Reflash Master handheld device
02USB cable and Kubota diagnostic cable
03Quick Reference Guide
04EGR blocker plate and OEM gasket
05DPF removal and EGR plate install instructions
OPTIONAL PIPING ADD-ON DPF bypass pipe Fills the gap once the DPF is out, for a clean, open exhaust. Choose DPF Bypass Piping above. Piping is not sold separately.

Handheld tuning process

STEP 01OrderYour Reflash Master kit ships out, usually in 1 business day.
STEP 02ReadPlug the handheld into your SVL90 and save a read of the ECM.
STEP 03SendEmail us the read file. Your tuned file comes back in about 2 hours.
STEP 04WriteLoad the tuned file onto the ECM and get back to work.
VIDEO TUTORIALSee the Reflash Master in actionWatch →

Why delete the DPF and EGR on a Kubota SVL90?

DPF

Diesel particulate filter

The SVL90 traps soot in its DPF and has to heat the exhaust to burn it out. Each regen costs fuel and time, and a filter that keeps loading up ends in a cleaning bill or a replacement. Turn it off and pull it, and the machine simply runs.

EGR

Exhaust gas recirculation

Recirculated exhaust carries carbon into the intake, where it builds on the EGR valve until it hangs open or seizes. That shows up as fault codes, lost power and derates. Our file closes the valve, and the blocker plate and OEM gasket in the kit seal it off for good.

Why tune with a handheld?

The SVL90 is tuned right at the machine, so there is no waiting on modules to travel back and forth.

01No shipping downtimeYour ECM never leaves the machine, so it can keep working until you are ready to tune.
02Yours to keepHang on to the Reflash Master and flash it back to stock later if needed.
03Fast turnaroundSend your read file and your tuned file is back in about 2 hours.

Frequently asked questions

Q1Why choose a Reimer Tuning reflash for my Kubota SVL90?+

We write our SVL90 files in house and back every tune with a 1 year software warranty. Tuned files come back in about 2 hours, and our team is a phone call away if you need help during the process.

Q2Can I use the handheld again later?+

Yes, the Reflash Master is yours to keep, and it can be unlocked through our server if you have another piece of equipment to tune. Contact us and we will walk you through the process.

Q3Can the DPF be removed?+

Yes. Our file turns off the DPF and its sensors, and the kit includes step by step instructions for taking the DPF filter out.

Q4Do the aftertreatment sensors need to stay connected?+

The exhaust gas temperature sensors must stay plugged in for CAN bus resistance. The differential pressure sensor does not need to be reconnected, and with a straight pipe the aftertreatment harness can simply be zip tied out of the way. The sensors do not have to go back into the exhaust.

Q5Will the horsepower tune increase fuel use?+

Our tunes raise output 10% or 20% with a linear map, so power arrives sooner. Run it at a lighter load and you can save fuel, with the extra power there when the job needs it.

Q6Do you ship to the United States and Canada?+

Yes. We ship the Reflash Master kit across Canada and the US, usually within 1 business day if overnight shipping is selected.

Q7Disclaimer+

This product is for off-road use only and cannot be used on machines registered for highway use. Check your provincial or state legislation before purchasing.

Why Reimer Tuning

Every SVL90 file is written in house and covered by a 1 year software warranty. Canadian owned since 2014, with real people on the phone when you need help mid-tune.

Off-road use only. Not for machines registered for highway use. Buyers are responsible for knowing their provincial or state legislation. All sales final.
