CAT Backhoe Loader EGR, DPF & DEF Tune

A backhoe loader moves between digging, loading and travel all day, and a clogged filter or failed DEF sensor can park it at the worst moment. C4.4-powered CAT backhoes at Tier 4 are tuned remotely through CAT ET with the ECM left in place. C3.6 and Stage V machines are bench flashed in our shop. The EGR, DPF and DEF systems are turned off in the software. We ship all across the US and Canada.

FitsCAT 415 to 450 backhoes
SystemsEGR · DPF · DEF/SCR
TierTier 4A · Tier 4B · Stage V
MethodRemote (bench for C3.6 / Stage V)
AdapterCAT Comm (remote)
Warranty1 year software
Emissions tuning onlyHorsepower tunes are not offered for CAT backhoe loaders. Your machine keeps its factory rating.
​
FIRST, FOR EVERY BACKHOESend us a photo of the engine data plateYou will usually find it on the side of the radiator or in the cab. From the plate we can see your engine size and tier, and tell you which process below to use.
Email data plate photo

Remote tune

C4.4 · Tier 4A & Tier 4B
STEP 01OrderChoose your tier, then add a CAT Comm adapter if you need one.
STEP 02ConnectPlug the adapter into the backhoe’s diagnostic port and open TeamViewer.
STEP 03FlashWe read the ECM through CAT ET and load your tuned file.
You’ll need
✓Windows laptop
✓TeamViewer installed
✓Strong internet connection
✓CAT Comm adapter
✓Battery charger
✓Key on, engine off
BEFORE STEP 02Download TeamViewer for WindowsDownload →

C3.6 or Stage V? Bench flash instead

Backhoes with the C3.6 engine, such as the next-generation 415, and any Stage V machine are programmed in our shop. After you order, we email the shipping and customs steps. Take out the ECM, send it to us, and refit it once it is back.

After the tune

EXHAUSTHollow out or straight pipe the DPFHollow out the DPF canister or swap in a straight pipe. On Tier 4B backhoes the DEF catalyst does not restrict flow and can remain.
EGRBlock-off plate recommendedOnce the tune turns the EGR off, we recommend bolting a block-off plate over the port. It works as a fail-safe, keeping the valve from lifting down the road.

CAT backhoe loaders we tune

Tier 4 F and F2 series backhoes, plus the next-generation 415 to 450.

415Next gen
416F · F2 · Next gen
420F · F2 · Next gen
430F · F2 · Next gen
440Next gen
450F · Next gen

Unsure which version you have? The data plate photo lets us confirm it before you order.

Why delete the EGR, DPF and DEF on a CAT backhoe?

EGR

Exhaust gas recirculation

Short trips, frequent stops and on-and-off digging keep a backhoe engine from running hot and steady. That is when the EGR does the most harm, laying down carbon in the valve and intake. A sticking valve brings warning lights, smoke and sluggish loader response. With the EGR off, the engine pulls in clean air only.

DPF

Diesel particulate filter

Backhoes spend much of the day idling between trucks or roading between jobs, so the DPF rarely gets hot enough to clean itself. Parked regens follow, often when the crew needs the machine most. Over time, the filter plugs and has to be removed for service. Turn the DPF off and empty the canister, and the backhoe stays on the job.

DEF

Diesel exhaust fluid / SCR

Municipal and contractor backhoes can sit for days and then work in freezing weather, which is hard on DEF. Old fluid crystallizes, frozen lines set faults, and a failed NOx sensor or pump cuts power when you need to dig. Switching the SCR off ends DEF refills and the derates that come with them.

Frequently asked questions

Q1Where is the data plate on a CAT backhoe?+

On most backhoes it is on the side of the radiator, and on some it is inside the cab. Email us a clear photo where every line can be read, before or right after you order.

Q2Is my backhoe tuned remotely or bench flashed?+

C4.4-powered backhoes at Tier 4A or Tier 4B are tuned remotely through CAT ET with the ECM left in place. Machines with the C3.6, such as the next-generation 415, and any Stage V backhoe are bench flashed. Your data plate tells us which one applies.

Q3Can I use my own CAT Comm adapter?+

Yes. Pick No Tool at checkout if you already own one. Otherwise choose Tooling Required and we ship the adapter with its software.

Q4What do I need for the remote tune?+

A Windows laptop with TeamViewer, a strong internet connection and the CAT Comm adapter. Connect a battery charger, and keep the key on with the engine off during the flash.

Q5What happens to the DPF and DEF catalyst?+

After the tune, the DPF must be hollowed out or replaced with a straight pipe. On Tier 4B machines the DEF catalyst stays on, because it does not restrict flow.

Q6Will my backhoe need an EGR block-off plate?+

We recommend one on every backhoe that has its EGR deleted. The tune turns the valve off, and the plate adds a fail-safe in case the valve ever tries to lift afterward.

Q7Can you add horsepower to my CAT backhoe?+

No. Our CAT backhoe service is emissions tuning only, and the engine keeps its factory rating.

Q8How fast do you ship?+

CAT Comm adapters usually ship within 1 business day to the US and Canada. Bench-flashed ECMs go back out as soon as they are programmed. Expedited orders placed after 12 ET ship the next day.

Q9Disclaimer+

Off-road use only. Not for machines registered for highway use. Buyers must know their state or provincial laws.

Why Reimer Tuning

Reimer Tuning is Canadian owned and has been tuning construction and farm equipment since 2014. Each CAT backhoe file is built in house for the engine on your data plate, and every remote session or bench flash is backed by a 1 year software warranty.

Emailing us? Attach a photo of your engine data plate.

Off-road use only. Not for machines registered for highway use. Buyers are responsible for knowing their provincial or state legislation. All sales final.
